Analyzer, Tango, P09

The following lines which are part of /online_dir/TkIrc.pl create a widget to operate analyzer at P09.

Figure 14.15: BLSC: Analyzer, P09

$Spc::res_h{ blsc} = "analyzer";
#
# analyzer
#
$Spc::res_h{ analyzer_title} = { text => "Analyzer"};
$Spc::res_h{ analyzer_help} = sub
{
    Util::display_text( "Help Analyzer",
'
n.n.
'
)};

$Spc::res_h{ analyzer_io1} = {
    label => { name => "Dhkl",
	       unit => "u",
	       get => sub { sprintf( "%g", Spectra::tng_attrDoubleRd( "analyzer", "Dhkl"));}},
    entry => { set => sub { Spectra::tng_attrDoubleWrt( "analyzer", "Dhkl", $_[0]);}}};
$Spc::res_h{ analyzer_io2} = {
    label => { name => "ThanaOffset",
	       unit => "u",
	       get => sub { sprintf( "%g", Spectra::tng_attrDoubleRd( "analyzer", "ThanaOffset"));}},
    entry => { set => sub { Spectra::tng_attrDoubleWrt( "analyzer", "ThanaOffset", $_[0]);}}};
$Spc::res_h{ analyzer_io3} = {
    label => { name => "UnitLimitMin",
	       unit => "u",
	       get => sub { sprintf( "%g", Spectra::tng_attrDoubleRd( "analyzer", "UnitLimitMin"));}},
    entry => { set => sub { Spectra::tng_attrDoubleWrt( "analyzer", "UnitLimitMin", $_[0]);}}};
$Spc::res_h{ analyzer_io4} = {
    label => { name => "UnitLimitMax",
	       unit => "u",
	       get => sub { sprintf( "%g", Spectra::tng_attrDoubleRd( "analyzer", "UnitLimitMax"));}},
    entry => { set => sub { Spectra::tng_attrDoubleWrt( "analyzer", "UnitLimitMax", $_[0]);}}};
