The Utils menu (7.10) contains the items:
| Cursor: Invokes the cursor widget for an active SCAN. The cursor widget can manouver through the list of SCAN GQEs. |
| Move to cursor: The scan device is moved to the current cursor position. |
| ESS (EXAFS Feature: Invokes the EXAFS sample scan menu (7.11). |
| Display:
|
The ESS menu (7.9) repeats EXAFS scans for different samples. It contains the following items:
| No. of Samples: |
| E-Cal.: Where the monochromator was calibrated. |
| Reg. File: The file that contains the EXAFS regions. |
| Name: The sample name. |
| MOT7: The motor that moves the sample into the beam. |
| Repeats: No. of repeats for a specific sample. |
| Comment: Additional information about the sample.
|
